46
DOS G 60 dispenser module
• For use on PG 8535
• For liquid alkaline detergents and
chemical disinfectants
• Peristaltic pump, adjustable via
machine's electronic controls
• Long siphon (300 mm) for 5 l and 10 l
canisters, incl. level fill monitoring
• Length of connection lead: 1.90 m
DOS G 10 dispenser module
• For use on PG 8535
• For liquid acidic agents (surfactant,
neutralising agent)
• Features as per DOS G 60
DOS NA 120
• For use on PG 8536
• Integrated bellows-type dispenser pump
incl. ultrasound flow control for pH-
neutral/alkaline detergents and chemical
disinfectants
• Retrofittable by Service
DOS S 20
• For use on PG 8536
• Integrated bellows-type dispenser pump
for surfactants and neutralising agents
• Retrofittable by Service
G 7896 dispenser unit
Housing unit for DOS modules and supply
containers for undercounter installation
• H 850 (820), W 300, D 600 mm
• Compatible with G 7881, G 7891
• Freestanding unit, can be built under
• Unit with removable door
• Outer panelling in stainless steel or white
• Interior dimensions: H 530, W 249, D 480
mm on 3 levels
Level 1: Removable pull-out drawer on
telescopic runners for DOS modules
Levels 2 and 3: Removable pull-out
drawer on telescopic runners with drip
tray and lock for canisters
Canister sizes
4 x 5l, 245 x 225 x 145 mm*
2 x 10 l, 140 x 193 x 307 mm
2 x 10 l, 223 x 203 x 321 mm
2 x 10 l, 229 x 193 x 323 mm
2 x 10 l, 194 x 204 x 353 mm
1 x 20 l, 289 x 233 x 396 mm
1 x 25 l, 288 x 234 x 456 mm
* Only possible with DOS K-60/1 dispenser with short siphon
Dispensing accessories
Dispenser modules and supply
containers can be optionally
accommodated in the G 7896 dispenser
cupboard or in an existing cabinet
DOS K 60 dispenser module
• For liquid alkaline detergents
and chemical disinfectants
• Peristaltic pump, adjustable via
machine's electronic controls
• Integrated dispenser monitoring function
ensuring high level of process security in
compliance with EN ISO 15883
• Long siphon (300mm) for 5 l and 10 l
canisters, incl level fill monitoring
• Length of connection lead: 1.90 m
• Option: Conversion kit, Part no. 5458030,
for siphon (10-30 l containers) available
from Spares.
Note
The use of liquid detergent is recommended in the VarioTD
programme.
