- page 53

53
*O = Upper basket, U = Lower basket, • = standard
PG 8536
Washer-disinfectors
PG 8535
PG 8536
Dispenser systems
1 dispenser pump for liquid acidic agents
• (Peristaltic pump)
• (Bellows-type pump)
1 dispenser pump for liquid detergent
• (Peristaltic pump)
• (Bellows-type pump)
1 connection for external DOS G10 or DOS G60 dispenser module
DOS S20 dispenser pump for neutralising agent and surfactant
Optional
DOS NA 120 dispenser pump for disinfectant or liquid detergent
Optional
Ultrasound flow control
Drawer for 2 x 5 l supply canisters
Drawer for 4 x 5 l supply canisters
Water softeners
for cold and hot water to max 70°C, Monobloc softener
for cold and hot water, max 70°C, large-capacity water softener
Steam condenser
Aerosol
Drying unit
Fan [kW]
0.3
0.3
Heater bank [kW]
2.3
2.3
Total rated load [kW]
2.6
2.6
Air throughput [m³/h]
60
60
Temperature selection in 1°C increments [°C]
60–115°C
60–115°C
Time selection in 1-minute increments [mins.]
1–240 mins.
1–240 mins.
Pre-filter EU 4, filter rating > 95%, filter life 100 h
Particulate filter/HEPA S-class filter H 13,
Filtration rate >99.992% (DIN EN 1822), life cycle 500 h
Dimensions/Weight
External dimensions H/W/D [mm]
820/900/700
1175/900/700
Cabinet dimensions H/W/D [mm]:
500/535/ O*=473, U*=516 500/535/ O*=473, U*=516
Weight [kg]
114
177
Casing
Stainless steel (AE)
Stainless steel
Stainless steel
Compliance with standards
DIN EN ISO 15883-1/2, EN 61010-2-40, EN 61326
Test certificates
VDE, VDE-EMC, MDD CE 0366, IP 20
