Technical data
G 7862
Washer-disinfectors
G 7862
Frontloading unit with bottom-hinged door, excl. baskets
•
Freestanding unit with lid, can be built under
•
Freshwater system, max. temperature 93°C
•
Circulation pump [Qmax. l/min.]
400
Controls/Programmes
MULTI NOVOTRONIC / 8 programmes
•
Electric door lock
•
Buzzer, acoustic signal at end of programme
•
Programme recontinuation in event of power outage
•
Serial interface for process documentation,
•
Water connections
1 x cold water, 0.5–10 bar flow pressure (50–1000 kPa)
•
1 x hot water, 0.5–10 bar flow pressure (50–1000 kPa)
•
No. of inlet hoses, ½" with ¾" threaded union, l = approx. 1.7 m
2
Drain pump DN 22, head height 100 cm
•
Steam condenser water drain (DN 22)
•
WaterProof System (WPS)
•
Electrical connection, supply lead approx. 1.7 m, 5 x 2.5 mm²
3N AC 400 V 50 Hz/convertible to AC 230 V 50 Hz*
•
AC 230 V 50 Hz/convertible to 3N AC 400V 50Hz*
•
Heating [kW] (3N/ AC)
8.5/6
Circulation pump [kW] (3N/ AC)
0.7/0.7
Total rated load [kW] (3N/ AC)
9.2/6.7
Fuse rating [A] (3N/ AC)
3 x 15-16/1 x 30
Dispenser systems
1 door dispenser for powder detergent
•
1 door dispenser for liquid surfactant
•
Connection options
DOS K 60 for liquid detergents/chemicals
1
* Conversion results in changes to cycle times (charges apply)
