LWM Module C conductivity meter
• For E 310/E 318 water demineralisation
cartridges
• H 118, W 235, D 110 mm
• Electrical connection AC 230 V 50 Hz
• 2 hoses, approx. 1.9 m,
3/4" threaded union
• Integrated conductivity meter:
Range: 0–20 µS/cm
1.5 µS/cm, corresponds to tridistilled
water
2.5 µS/cm, corresponds to bidistilled
water
20.0 µS/cm, corresponds to single-
distilled water
Accessories for reprocessing
with fully demineralised water
G 7895/1 Aqua Purificator
•For use on G 7881, G 7891
• Housing unit for 2 x E 310/E 318
demineralisation cartridges
• Integrated conductivity meter
• Generally recommended quality for final
rinse < 15 µS/cm
• H 850 (820), W 300, D 600 mm
• Freestanding unit, can be built under
• Outer panelling in stainless steel or white
• Electrical connection AC 230 V 50 Hz
•Water connection:
1 x cold water, 3/4" threaded union
1 x connection between cartridge and
machine, 2.5 - 10 bar flow pressure to
cartridge
(pressure loss approx. 1 bar per cartridge)
E 310 full demineralisation cartridge
charged
• Pressure-proof stainless-steel cartridge
• H 570, Ø 240 mm
• Complete with vent and pressure relief
valve
•Contains 20 l of reusable mixed resin
Delivery capacity in l depends on the total
salt content of the raw water and the max.
acceptable conductivity.
Conductivity
5 µS/cm 10 µS/cm
5° dH 4,250 4,500
10° dH 2,125 2,250
15° dH 1,420 1,500
20° dH 1,070 1,125
25° dH 850 950
30° dH 710 750
The information provided in this chart is
intended as a guide only
E 318 full demineralisation cartridge,
empty
• Can be charged with 20 l of single-use
resin
Disposable resin
• 20 l homogenous, mixed-bed resins for
E 318
• Box with 2 bags x 10 l, vacuum-sealed in
plastic bags
• Replacement filter bag
E 316 refill set
• Plastic barrel with lid and funnel for 30 l
of disposable resin
