E 442 irrigation sleeve
4
• For MIS instruments, 4-8 mm,
screw thread
• Length 121 mm, 11 mm
• Cap, 6 mm
(Mat. no. 4174960)
• Clamp (Mat. no. 4174850)
Clamp
(Mat. no. 4174850)
E 443 irrigation sleeve
5
• For MIS instruments,
8-8.5 mm
• Length 121 mm, 11 mm
• Cap, 10 mm
(Mat. no. 4174970)
• Clamp
(Mat. no. 4174850)
E 445 caps
• 12 caps for irrigation sleeves
• 6 mm
E 446 caps
• 12 caps for irrigation sleeves
• 10 mm
E 456 spring stay
1
• For MIS instruments
E 475 holder bracket
2
• For MIS insert
• To secure irrigation sleeves
(Mat. no. 4692430)
E 469 irrigation sleeve
1
• For MIS instruments/
urology
• Length 300 mm, 11 mm
• Cap, 6 mm
(Mat. no. 4174960)
• Clamp
(Mat. no. 4174850)
E 467 irrigation sleeve
2
• For MI instruments/forceps
• Length 205 mm, 11 mm
E 336 irrigation sleeve
3
• Length 121 mm, 11 mm
E 447 adapter, female
1
• For LuerLock, male, screw
thread for E 450/1,
O 176, O 183
E 449 adapter, male, without
centre pin*
2
• For LuerLock, female, screw
thread for E 450/1,
O 176, O 183
E 452 injector nozzle
3
• Length 60 mm, 2.5 mm,
screw thread, for mobile
injector unit
E 453 injector nozzle
4
• Clip bracket
• Length 110 mm, 4 mm, screw
thread, for mobile injector
unit
E 448 silicone hose
5
• LuerLock adapter, male
• Length 300 mm, 5 mm
• Nozzle, 8 x 1 mm thread
* Adapter with centre pin
available from Spares,
Mat. no. 4224230.
E 464 adapter
• For injector nozzle E 454,
13 x 65 mm
• Height-adjustment clip
(Mat. no. 4692440)
E 454 injector nozzle
• For trocar sleeves
10-15 mm, 8 x 150 mm
• Height-adjustment spring
(Mat. no. 4692430)
E 471 spring clamp
• For injector nozzle
2.5 mm, for E 452
E 472 spring clamp
• For injector nozzle
4.0 mm, for E 351, E 453
1 2 3 4 5
1 2 3 4 5
MIS accessories
