29
Inserts
E 106 insert 1/2 (illustrated)
• For ENT instruments (e.g. ear funnels)
• 10 spring hooks, H 175 mm
• 16 spring hooks, H 105 mm,
Spacing approx. 60 mm
• H 186, W 195, D 430 mm
E 106/1 insert 1/2
• 26 small spring hooks, H 105 mm,
Spacing approx. 60 mm
• H 116, W 195, D 410 mm
E 106/2 insert 1/2
• 13 large spring hooks, H 175 mm,
spacing approx. 85 mm
• H 186, W 180, D 420 mm
E 125 insert 1/1* (illustrated)
• For 9 bottles, 2,000 ml
• 9 compartments, compartment sizes
(bottle) 125 x 125 mm
• Compartment size (neck) 55 x 55 mm
• H 224, W 460, D 460 mm
E 124 insert 1/1*
• For 16 bottles, 1,000 ml
• 16 compartments, compartment sizes
(bottle) 100 x 100 mm
• Compartment size (neck) 48 x 48 mm
• H 148, W 460, D 460 mm
E 129 insert 1/1
• For 20 bottles, 500 ml
• 20 compartments, compartment sizes
(bottle) 84 x 84 mm
• Compartment size (neck) 46 x 46 mm
• H 113, W 445, D 445 mm
E 128 insert 1/1
• For 24 bottles, 250 ml
• 24 compartments, compartment sizes
(bottle) 71 x 71 mm
• Compartment size (neck) 46 x 46 mm
• H 103, W 445, D 445 mm
E 127 insert 1/1
• For 44 bottles, 100 ml
• 44 compartments, compartment sizes
(bottle) 57 x 57 mm
• Compartment size (neck) 46 x 46 mm
• H 102, W 445, D 445 mm
E 126 insert 1/1 (illustrated)
• For 48 bottles, 50 ml
• 48 compartments, compartment sizes
(bottle) 45 x 45 mm
• Compartment size (neck) 28 x 28 mm
• H 83, W 445, D 445 mm
Description
• Baskets and inserts only suitable for the
simple cleaning of infusion bottles
• Neither direct injection nor double spray
system according to GMP guidelines.
* Not for use in upper basket
