22
E 367 mobile injector unit with drying
connection
For use in PG 8535, PG 8536
• For intubation material
• 20 nozzles 2.5 x 30 mm
• 20 nozzles 4.0 x 30 mm
• 40 spring clips for nozzles
• 1 x E 378 insert 1/1 mesh tray
H 80 + 30, W 460, D 460 mm
• Connection for hot-air drying unit
•With holder for ML/2 magnetic strip for
automatic mobile unit recognition
• H 502, W 535, D 515 mm
E 368 mobile injector unit with drying
unit for intensive care
For use in PG 8535, PG 8536
• For narrow-gauge breathing tubes, fitted
with:
• 10 nozzles, 4.0 x 30 mm with spring
supports
• 14 nozzles, 6.0 x 220 mm with spring
supports
• 2 x E 431 injector nozzles for breathing
bags, 8 x 193 mm
• 1 instrument box, UTS/1
H 93, W 102, D 180 mm
• Connection for hot-air drying unit
•With holder for ML/2 magnetic strip for
automatic mobile unit recognition
• H 502, W 535, D 515 mm
U 167 lower basket for anaesthetic
equipment
For use in PG 8535, PG 8536
• For 4 soda lime containers, 9 secretion
jars and various other utensils
• 20 x 200 mm holders, spacing approx.
95 mm
• Plastic-coated
• H 220, W 535, D 516 mm
E 496 injector nozzle
• For intubation material, 4 x 120 mm
Anaesthetic equipment
E 381 mobile injector unit with drying
connection
For use in PG 8535, PG 8536
• For intubation material
• 20 nozzles, 4.0 x 30 mm with spring
supports
• 5 nozzles, 2.5 x 30 mm (supplied)
• 6 x E 466 injector nozzles for breathing
bags, 8.0 x 333 mm
• 2 x E 431 injector nozzles for breathing
bags, 8.0 x 193 mm
• Connection for hot-air drying unit
•With holder for ML/2 magnetic strip for
automatic mobile unit recognition
• H 502, W 535, D 515 mm
