E 905/1 modular insert
• For short MIS instruments
• 16 receptacles
• Sectioned for arthroscopes,
laparoscopes etc.
• H 40, W 461, D 510 mm
Supplied as standard with:
• 1 x E 336 MIBO injector sleeve for
pipettes/MIS instruments
• 2 x E 362 blanking screws
• 1 x E 442 injector sleeves for MIS
instruments, 4–8 mm
• 2 x E 447 female adapters,
for male LuerLock
• 4 x E 448 silicone hoses, 300 mm,
5 x 1.5 mm with male LuerLock adapters
• 2 x E 449 male adapter,
for female LuerLock
• 4 x E 452 injector nozzles, 2.5 x 60 mm
• 3 x E 453 injector nozzles,
4.0 x 110 mm with spring supports
• 3 x E 454 injector nozzles for trocar
sleeves, 10-15 mm
• 1 x E 464 sleeve
for E 454 injector nozzles
• 1 x E 472 spring support for injector
nozzle, 4 mm
• 1 x E 907/1 insert / mesh tray with lid for
small parts
E 903/1 modular insert
• For TUR sets (transurethral resection)
• 10 receptacles
• H 40, W 461, D 510 mm
Supplied as standard with:
• 3 x E 442 irrigation sleeves, 121 mm,
for MIS instruments, 4–8 mm
• 1 x E 444 insert/spiral rack for fibre optic
cables and irrigation tubes
• 1 x E 447 female adapters,
for male LuerLock
• 4 x E 448 silicone hoses,
300 mm, 5 x 1.5 mm with male LuerLock
adapters
• 3 x E 453 injector nozzles,
4.0 x 110 mm with spring supports
• 1 x E 454 irrigation sleeve for bladder
syringe or trocar sleeve
• 3 x E 467 injector sleeves, 205 mm,
for MIS instruments/forceps
• 3 x E 469 injector sleeves, 300 mm,
for MIS instruments/urology
• 1 x E 907/1 insert / mesh tray with lid for
small parts
• 2 m silicone hose, Ø 5 mm
• 2 plastic supports, for use in E 474/1, E
902/1 mobile units
E 919
For connection of 10 turbines/hand-pieces
and contra-angles as well as dental and
ENT instruments
• For use in E 474
• Reprocessing using VARIO TD programme
• Cleaning should be performed using
neutral to mildly alkaline liquid detergents
• Combination with MIS instruments
possible
• Scope of delivery: 10 receptacles for
transmission instruments, without
adapters (ADS 1-3)
E 906/1 modular insert
• For long shafted MIS instruments
• 10 receptacles
• Sectioned for arthroscopes, laparoscopes
etc.
• H 40, W 461, D 510 mm
Supplied as standard with:
• 1 x E 336 MIBO injector sleeve for
pipettes/MIS instruments
• 2 x E 362 blanking screws
• 5 x E 442 injector sleeves for
minimally invasive instruments, 4–8 mm
• 3 x E 443 injector sleeves for MIS
instruments, 8–12 mm
• 2 x E 448 silicone hoses, 300 mm,
5 x 15 mm with male LuerLock adapters
• 1 x E 454 injector nozzles for trocar
sleeves, 10-15 mm
• 2 x E 456 spring stays
for MIS instruments
• 1 x E 464 sleeve
for E 454 injector nozzles
• 1 x E 908 insert for separable
MIS instruments/inner shafts
