E 436/3 mobile injector unit TA
For use in PG 8536
• For approx. 3 AN sets
• 8 nozzles with spring supports for
breathing tubes with max. length of 1.5 m
• Spiral support
• Connection for hot-air drying unit
•With holder for ML/2 magnetic strip for
automatic mobile unit recognition
• H 507, W 535, D 515 mm
E 435/3 mobile injector unit TA
For use in PG 8535
• For approx. 2 AN sets
• 6 nozzles with spring supports for
breathing tubes with max. length of 1.5 m
• Spiral support
• Connection for hot-air drying unit
•With holder for ML/2 magnetic strip for
automatic mobile unit recognition
• H 507, W 535, D 515 mm
E 461/2 mobile injector unit TA
For use in PG 8535, PG 8536
• For 12 breathing tubes up to 1.5 m long,
fitted on a spiral rack
• 1 x E 432 holder,
for 4 breathing tubes
• 3 x E 433 holders,
for 4 silicone tubes, included
• 1 x E 434 holder for 4 paediatric
breathing tubes, included
• 1 x E 430/1 mesh tray
• Connection for hot-air drying unit
•With holder for ML/2 magnetic strip for
automatic mobile unit recognition
• H 502, W 535, D 515 mm
E 435/3 and E 436/3 scope of delivery:
• 1 x E 430 mesh tray
• 1 x E 432 holder for 3-4 corrugated
breathing tubes
• 2 x E 433 holders for
3-4 silicone breathing tubes1)
• 1 x E 434 holder for
3-4 paediatric breathing tubes
• 6 x E 466 injector nozzles for breathing
bags, 8 x 333 mm
• 1 x E 431 injector nozzle for breathing
bags, Ø 8 x 193 mm
• 10 x E 496 injector nozzles, 4 x 120 mm
Anaesthetic equipment
Sample combination
Carriage with E 505 module for intubation
material
Sample combination
E 501 carriage with E 502 hose module
1
) Pre-fitted
Model
Anaesthetics/modular system
Mobile units
for anaesthetic equipment
PG 8535
E 501
E 502
E 505
E 435/3
E 461/2
PG 8536
–
–
–
E 436/3
E 461/2
