E 505 module for intubation material
For use in E 501
•Module for intubation material
• 30 injector nozzles to connect intubation
material, e.g. laryngeal masks, Guedel
tubes or endotracheal tubes
Scope of delivery:
• 30 x E 496 injector nozzles for intubation
material, Ø 4 x 120 mm
Anaesthetic equipments/modular system
Modular basket concept
Miele is now offering a new and modular
mobile unit design for the reprocessing of
anaesthetic instruments and accessories.
This concept comprises a basic load
carrier and modules for anaesthetic tubing
and intubation material. Anaesthetic
equipment and accessories can be
reprocessed flexibly to meet the needs of
individual surgeries. A further E 427 for
6 laryngoscopes further complement the
system.
E 502 module for breathing tubes
For use in E 501
•Module for 6 breathing tubes
• 6 nozzles with spring supports
• Support for breathing tubes with
max. length of 1.5 m
• Spiral support
Scope of delivery:
• 2 x E 433 holders for 3 silicone breathing
tubes
• 1 x E 434 holder for 3 paediatric
breathing tubes
• 1 x E 432 holder for 3 corrugated
breathing tubes
E 501 carriage
For use in PG 8535
• For modules E 502, E 505
• For approx. 2 AN sets in combination
with E 502
• 6 injector nozzles for breathing bags,
breathing masks
• 10 injector nozzles for intubation material
• Connection for hot-air drying unit
•With holder for ML/2 magnetic strip for
automatic mobile unit recognition
• H 502, W 535, D 515 mm
E 501 scope of delivery
• 6 x E 466 injector nozzles for breathing
bags, 8 x 333 mm
• 10 x E 496 injector nozzles for intubation
material, Ø 4 x 120 mm
• 1 x E 431 injector nozzle for breathing
bag
• 1 x E 507 mesh basket for sundry small
items
• 8 x irrigation tubes for double-lumened
laryngeal masks, Ø 4 x 70 mm
