58
SegoSoft Miele Edition –
Products and accessories
SegoSoft Miele Edition:
Process documentation software
for direct PC connections or network
connections
'Comfort Plus' package
with extended functionalities
• Documentation of process data,
routine checks, maintenance
• Advanced digital signature with reference
to user in PDF document
• User-referenced approval of process
protocols with user name and password
• User administration for any number of user
names/passwords
• Backup function for automatic data
backup
Scope:
• Software CD, Comfort Plus software
package, installation instructions
• Licence card for 1 machine
• Optional: Additional licence for further
units
• Free support
Free over-the-telephone installation
support for 30 days, software installation
and start-up instructions
Connectable model types:
• Serial connection: max. 4 machines
Network connection: Any number of
machines
Connection cables
to be ordered separately
Segosoft Miele Edition/USB solution
Process documentation software
for data transfer using USB stick
'Comfort' software package
with basic functionalities:
• Documentation of process data
• Simple digital signature
• User-referenced approval
on enclosed signature pad
• Optional: Software upgrade to
Comfort Plus, e.g. for digital approvals
with user name and password,
further functions, cf. Comfort Plus
software package
Scope:
Complete package for 1 machine
• Software CD, Comfort software package,
installation instructions
• USB stick
• USB data logger
H x L x W: 31 x 90 x 109 mm,
incl. 230 V converter, 1.4 m supply lead
• Serial interface cable
to connect machine and data logger
(cable length: 3 m)
Connectable model types:
•max. 1 machine
• Optional: Connection of up to 5 machines
possible using software upgrade to
Comfort Plus
Net500 network converter
Net500 network converter for connection
of machines with serial interface to surgery
network, data conversion from RS 232 to
network format (TCP/IP)
Scope:
• Network converter
H x L x W: 31 x 90 x 109 mm
incl. 230 V converter, 1.4 m supply lead
PRT100 protocol printer
Printer to print process protocols, ink-jet
printer with indelible ink
Further additional components
To connect a machine to a PC, Miele offers
a range of approved cables. Miele can also
advise on the choice of suitable software
and hardware.
