17
O 188/2 upper basket/open front
• Open front
• For various inserts
• Vertical clearance 165 +/- 20 mm
• Built-in spray arm with magnetic tip
• Note: Magnet for spray arm sensors on
PG8535, PG8536
• H 215, W 531, D 475 mm
O 190/2 upper basket/open front
• Open front
• For various inserts
• Vertical clearance 215 +/- 20 mm
• Built-in spray arm with magnetic tip
• Note: Magnet for spray arm sensors on
PG8535, PG8536
• H 265, W 531, D 475 mm
O 191/1 upper basket/open front
• Open front
• For mesh tray (E 142)
• Vertical clearance 115 +/-20 mm
• Loading width 475 mm
• Loading depth 450 mm
• Built-in spray arm above basket
• H 180 +/–20 mm
W 531, D 475 mm
Upper and lower baskets
for washer-disinfectors
G 7862, PG 8535, PG 8536
U 874/1 lower basket/open front
• For various inserts
• Vertical clearances in combination with
upper basket:
O 176 approx. 110 mm
O 177/1 approx. 220 mm – 20/– 40 mm
O 183 approx. 185 mm +/–20 mm
O 188/1 approx. 270 mm +/–20 mm
O 190/1 approx. 220 mm +/– 20 mm
O 191/1 approx. 295 mm
•With holder for ML/2 magnetic strip for
automatic mobile unit recognition
• H 50, W 534, D 515 mm
