63
Model number
CS 1234–1 i
CS 1312 BG
CS 1327 Y
Heating
Type of heating
Induction cooktop
Electric barbecue
Tepan Yaki
Type of appliance
CombiSet element
•
•
•
Design
Stainless steel trough/frame
•
•
•
Cast iron pan support (matt black enamel)
–
–
–
Cooking zone
Position/Type/Diameter in mm
front left/vario/140 – 200
–/–/–
–/–/–
Nominal rating
1.85 kW/3.0 kW/–
–/–/–
–/–/–
Cooking zone
Position/Type/Diameter in mm
rear left/vario/140 – 200
–/–/–
–/–/–
Nominal rating
1.85 kW/3.0 kW/–
–/–/–
–/–/–
Cooking zone
Position/Type/Diameter in mm
rear right/vario/160 – 230
–/–/–
–/–/–
Nominal rating
2.3 kW/3.0 kW/3.7 kW
–/–/–
–/–/–
Cooking zone
Position/Type/Diameter in mm
front right/vario/100 – 160
–/–/–
–/–/–
Nominal rating
1.4 kW/2.2 kW/–
–/–/–
–/–/–
Cooking zone
Tepan surface/Cooking area in mm/Tepan power level in kW –/–
–/–
190 x 290/2.4
Grilling surface in mm/Grill power in kW
–/–
250 x 210/3.0
–
Convenience features
Dial controls
•
•
•
Indicators
Residual heat indicator
•
–
•
Temperature reached indicator
–
–
–
Safety
Residual heat/Booster/In-operation
•
/–/
•
–/–/
•
•
/–/
•
Obstruction sensor
–
–
–
Technical data
Dimensions in mm (W x D)
576 x 520
288 x 520
380 x 520
Casing height incl. connection box in mm
76
120
78
Cut-out dimensions in mm
560 x 500
272 x 500
364 x 500
Total connected load in kW/Voltage in V
7.4/230
3.0/230
2.6/230
Minimum clearance below rangehood
–
–
–
Standard accessories
Glass scraper/Connection cable
–/
•
–/
•
–/
•
Lava rock/Cleaning brush
–/–
•
/
•
–/–
