KM 6367
1. Front
2. Casing depth
3. Mains connection bos, mains connection cable,
L = 1440 mm, supplied loose
4. Stepped cut-out
NB; only suitable for installation in granite, marble,
tiled or solid wood worktops. For other materials
please ask manufacturer, if building-in is possible.
KM 6379
1. Front
2. Casing depth
3. Miele@home connection
4. Mains connection box, mains connection cable
L = 1440 mm, supplied loose
KM 6386
1. Front
2. Casing depth
3. Miele@home connection
4. Mains connection box, mains connection cable
L = 1440 mm, supplied loose
Gas cooktops
The final space requirements
for the gas connection should
be checked with a licensed
gas fitter,
in order to conform to local
and national regulations
KM 2312 G
1. Front
2. Height for building in
3. Gas connection R 1/2 - ISO 7-1 (DIN EN 10226),
4. Mains connection box cable, 2000 mm long
KM 362-1 G
1. Front
2. Mains connection box
3. Gas connection R 1/2 - ISO 7-1 (DIN 2999)
KM 2334 G
1. Front
2. Height for building in
3. Gas connection R 1/2 - ISO 7-1 (DIN EN 10226),
4. Mains connection box cable, 2000 mm long
KM 2012 G
1. Front
2. Height for building in
3. Gas connection R 1/2 - ISO 7-1 (DIN EN 10226),
4. Mains connection box cable, 2000 mm long
KM 2354 G
1. Front
2. Building-in depth
3. Gas connection R 1/2 - ISO 7-1 (DIN EN 10226)
4. Mains connection box with mains connection cable
L = 2000 mm
