DFG 200 Ventilation grille
For all extraction mode rangehoods
Stainless steel ventilation grille for installation in an
external wall. Extraction connection: 200 mm Ø.
Dimensions: 310 x 310 x 80 mm (H x W x D)
Reducing collar
For all extraction mode rangehoods, to reduce the
size of the extraction connection. Please note, this
may increase the operating sound and reduce the
airthrough put performance of the rangehood.
from 200 to 150 mm Ø
from 150 to 125 mm Ø
DKS Condensate trap
For all extraction mode rangehoods with a built-in
fan
For trapping condensate, e.g. for ducting systems
that pass through several storeys and where there
is a difference in temperature (recommended
for temperate to cold climate installations).
DKS 125 for 125 mm Ø
DKS 150 for 150 mm Ø
DMK 150 Wall vent kit
DAS Flexible aluminium ducting
1.25 m long, extends to 5 m, recommended for all
rangehoods, in preference of highly flexible
concertina type ducting.
DAS 125 for 125 mm Ø (under space constrictions)
DAS 150 for 150 mm Ø (recommended for most)
DAS 200 for 200 mm Ø (high-performance models)
DDF Roof vent kit
For all extraction mode rangehoods
For venting through the roof. Suitable for roof
inclines up to 22° and for all types of roof tile, not
suitable for flat or asbestos roofing.
Stainless steel casing with lead collar, ducts
vapours downwards.
DDF 125/150 extraction connection 150 mm Ø
Accessory: Reducing collar for 125 mm Ø
DDF 200 extraction connection 200 mm Ø
For all extraction mode rangehoods
Sealed, insulated wall vent kit with non-return flap
for installation in an external wall.
Extraction connection for 150 mm Ø
Colour: grey, extraction grille in stainless steel
Con@ctivity
XKM 2100 KM
For all induction cooktops with DirectSelection
Plus controls
Cooktop components for transferring appliance
data to communication module XKM 2000 DA, for
connection to Con@ctivity enabled induction
cooktops.
Installation must be carried by a Miele Service
Technician or suitable qualified person
Dimensions: 6 x 17 x 14 cm ( H x W x D)
Control cable kit for
Con@ctivity XKM
For installing Con@ctivity module
XKM 2000 DA in rangehoods
DA 6000 W
DA 7090 W and DA 7000 D
Con@ctivity
XKM 2000 DA
For all wall-mounted and island rangehoods with
run-on function and grease filter saturation
indicator.
Rangehood components for processing appliance
data from communication module XKM 2100 KM,
for integration in Con@ctivity enabled rangehoods.
Installation must be carried out by a Miele Service
Technician or suitably qualified person.
Note: To install Con@ctivity in a DA 489-4, DA 6000
W, DA 7090 W or DA 7000 D a separate control
cable kit is required.
Dimensions: 5 x 10 x 12 cm (H x W x D)
