Installation diagrams
KFNS 37432 iD, KFNS 37452 iDE,
KFNS 37682 iD
Installation possibilities to mains water
KFNS 37692 iDE
Correct installation and ventilation
The ventilation of your integrated or built
under Miele refrigerator, freezer or wine
conditioner is a very important factor that
must be considered during installation. In
order for your integrated or built under
unit to operate correctly, all information
outlined within the operating instructions
regarding ventilation requirements must
be adhered to. Incorrect installation and
ventilation may cause unnecessary faults
with your appliance that may not be
covered under warranty.
*Please note that the outlined installation
diagrams are based on minimum
ventilation requirements
KWT 6321 UG
KS 37422 iD. KS 37472 iD, FNS 37402 i
KFNS 37692 iDE
*If adjoining kitchen units are taller a filler panel to match your kitchen furniture needs to be fitted to the appliance using the bracket supplied
