Product Information
Miele
Model no
WT 2780 WPM
Capacity
5.5 kg HoneycombCare drum
●
Washing capacity (kg)
5,5
Drying capacity (kg)
2,5
Colour options
Lotus White
●
Performance/Consumption data1)
Energy Efficiency Star rating
3
)
4
Energy consumption (kWh/year)
77
4
)
Energy Efficiency Star rating
3
)
4
Energy consumption (kWh/year)
200
5
)
Water Efficiency Star rating (WELS)
6
)
4
Water consumption (l/wash)
51
7
)
Spin speed options
Minimum rpm
400
Maximum rpm
1600
Rinse Hold and No Spin
●
Controls and display
Control panel Straight
Straight
Dial control
●
Plus LCD display
●
Buzzer option
●
Programme sequence indication
●
Excess detergent indication
●
Features
Direct enamel front
●
Removable panels
●
Delay start
●
Time remaining display
●
Ergonomic door opening (30 cm)
●
Unique Honeycomb Care
●
Load size and dispensing recommendation
●
Drum lighting
●
Anti-crease action
●
Dryer functionality
Condenser
Automatic moisture sensor drying
●
Drying overload indicator
●
Drain pump for condenser dryer
●
Maximum no. of drying levels
7
AutoClean detergent dispenser drawer
●
Standard washing and drying programmes
(wash temp. shown in brackets)
Automatic plus (Cold – 40°C)
●
Cottons (Cold – 95°C)
●
Minimum iron (Cold – 60°C)
●
Delicates (Cold – 60°C)
●
Woollens (Cold – 40°C)
●
Silks (Cold – 30°C)
●
Express 20 (Cold – 40°C)
●
Denim (Cold – 60°C)
●
Shirts (Cold – 60°C)
●
Dark garments (Cold – 40°C)
●
Outerwear (Cold – 40°C)
●
Sportswear (Cold – 60°C)
●
Trainers (Cold – 40°C)
●
Proofing (40°C)
●
Soft toys (Cold – 40°C)
●
Hygiene (30 – 95°C)
●
Pillows (Cold – 95°C)
●
First Wash (Cold – 40°C)
●
Special wash programmes
Curtains (Cold – 40°C)
●
Separate rinse
●
Starch
●
Drain/Spin
●
Special drying programmes
Timed drying warm air
●
Timed drying cool air
●
Smoothing
●
Freshen up
●
Rinse out fluff
●
Miele
Model no
WT 2780 WPM
Additional wash programme options
Standard running times with Short option
●
Delay start
●
Water plus
●
Stains
●
Extra quiet
●
Extra rinse
●
Soak option
●
Pre-Wash
●
Additional drying programme options
Low temperature
●
Programmable options for washing and drying
●
Choice of different languages
●
Buzzer volume (loud/normal/off)
●
Keypad tones (on/off)
●
Energy-saving stand-by mode
●
12 h/24 h clock
●
Temperature °C/°F
●
Display brightness/contrast
●
Lock code
●
Anti-crease action (on/off)
●
Distribution controller
●
Programmable options for washing
Memory
●
Gentle action
●
Suds cooling
●
Longer pre-wash cottons
●
Programmable options for drying
Door lock
●
Drying levels
●
Extended cool down
●
Safety features
Water Control System
●
Check drain/inlet indication
●
Automatic safety door lock
●
In-operation lock
●
Fault diagnosis
●
Emergency door release
●
Easy access manual drain
●
Water inlet filter
●
Dimensions and weight
Height (adjustable) (cm)
85
Width (cm)
59,5
Depth (cm)
58
Depth with door open (cm)
97,5
Net weight (kg)
101
Electrical Connection
Voltage (50 Hz) V
230
Fuse rating A
10
Total rated load kW
2,3
Power cable with plug m
1,5
Water connection via 1.5 m pressure hose with 3/4 inch (19 mm)
threaded union
cold
Water supply pressure min. - max. bar
1–10
Drain connection m
1,5
Maximum drain pump height/length m
1/5
Radio, TV & mains interference suppressed
●
Operating instructions and warranty
●
1
) According to AS/NZS 2040.2 (washing) & AS/NZS 2442.2 (drying)
2
) These programmes can also be set for timed drying for periods of between
15 minutes and 2 hours
3
) For more details, please ref.
4
) using Cottons Normal program once per week, when tested in accordance with
Standard AS/NZS 2442.2
5
) using Cottons 40°C program seven times per week, when tested in accordance with
Standard AS/NZS 2040.2
6
) For more details, please ref.
7
) using Cottons 40°C program, when tested in accordance with Standard AS/NZS 6400
N.B.These appliances conform to Australian Safety Regulations and must be installed in
accordance with national and local regulations by a competent person.
