44
Model number
KM 2334 G
KM 2354 G
KM 2357 G
Heating
Type of heating
Gas
Gas
Gas
Type of appliance
Cooktop with onset controls
•
•
•
Design
Toughened glass
–
–
–
Stainless steel frame
–
–
–
Stainless steel trim front and back
–
–
–
Bevelled edges
–
–
–
Stainless steel trough
•
•
•
Cast iron pan supports (matt black enamel)
•
•
•
Cooking zones
Number of cooking zones
5
5
5
Cooking zone
Position/Type/Pan base-pan rim diameter in mm
Front left/small burner/
100 – 220
Front left/small burner/
100 – 220
Front left/small burner/
100 – 220
Nominal rating
1.1 – 4.0 MJ/hr
1.2 – 4.0 MJ/hr
1.2 – 4.0 MJ/hr
Cooking zone
Position/Type/Pan base-pan rim diameter in mm
Rear left/medium burner/
100 – 220
Rear left/large burner/120 – 240 Rear left/large burner/120 – 240
Nominal rating
1.2 – 8.0 MJ/hr
1.7 – 9.7 MJ/hr
1.7 – 9.7 MJ/hr
Cooking zone
Position/Type/Pan base-pan rim diameter in mm
Centre/Mono-Wok/150 – 260 Centre/Dual-Wok/150 – 260 Centre/Dual-Wok/150 – 260
Nominal rating
5.2 – 15.5 MJ/hr
0.8 – 16.0 MJ/hr
0.8 – 16.0 MJ/hr
Cooking zone
Position/Type/Pan base-pan rim diameter in mm
Rear right/medium burner/
100 – 220
Rear right/medium burner/
100 – 220
Rear right/medium burner/
100 – 220
Nominal rating
1.2 – 8.0 MJ/hr
1.3 – 6.0 MJ/hr
1.3 – 6.0 MJ/hr
Cooking zone
Position/Type/Pan base-pan rim diameter in mm
Front right/medium burner/
100 – 220
Front right/medium burner/
100 – 220
Front right/medium burner/
100 – 220
Nominal rating
1.2 – 6.0 MJ/hr
1.3 – 6.0 MJ/hr
1.3 – 6.0 MJ/hr
Cooking zone
Position/Type/Pan base-pan rim diameter in mm
–/–/–
–/–/–
–/–/–
Nominal rating
–
–
–
Convenience features
Dial controls
•
•
•
Minute minder
–
–
–
Single-handed electronic ignition/QuickStart
•
/–
•
/–
–/
•
Easy maintenance
Easy clean ceramic glass
–
–
–
Dishwasher-proof pan supports
•
•
•
Safety
Safety switch-off
–
–
•
System lock
–
–
–
Heat indicator/In-operation indicator
–/–
–/–
–/–
Rapid switch-off
–
–
–
GasStop/GasStop & ReStart
•
/–
•
/–
–/
•
Technical data
Appliance dimensions in mm (W x D)
770 x 508
888 x 508
892 x 512
Casing depth incl. electrical connection box in mm
94
89.5
115
Required clearance below rangehood in mm
650
650
650
Cut-out dimensions in mm (W x D)
750 x 490
862 x 490
880 x 500
Total connected load in kW/Voltage in V
0.025/230
0.025/230
0.025/230
Standard accessories
Glass scraper/Connection cable
–/
•
–/
•
–/
•
Liquid gas jet kit/Ready for connection to natural gas
•
/
•
•
/
•
•
/
•
Wok ring
•
•
•
Gas cooktops
Product overview
